HD-005-G

The HD-005-G is made with the sight notch left uncut, so it can be machined to whatever size and notch configuration the user wants. It can also be used for shorter-than-standard height applications to solve zeroing problems if needed. You can cut your own notch, or Harrison Design will machine one to your dimensions for $35. If you'd like our assistance with this, please email john@HarrisonCustom.com to schedule it and discuss your needs.

Features include:

• Flat rear blade with 50 lpi serrations to reduce glare
• All edges and corners machine radiused for snag-free comfortable carry. Will not cut your hand during "over-hand" slide lock manipulation like some competitors sights
• Flat front face in adequarte size for one-handed slide manipulation
• 8-32 set screw for added security in dovetail
• Made in the USA

The HD-005 is made to the standard .375" blade height and will easily replace other brands of the same height.

My HD-004/005 rear sights will fit the popular Novak LoMount ® dovetail, which is found on fixed sight 1911s offered by Les Baer, Ed Brown, Colt's XSE and Gunsite models, Nighthawk Custom, Rock River, Springfield Armory, Dan Wesson, Wilson Combat and others.  My HD-004 / 005 sights will fit your slide with minor hand fitting of the sight, if the correct sight cut is already made; otherwise your slide will need to have the .495" X 65 degree sight cut machined.

NOTE: The HD-004/005 sights DO NOT fit: Kimber, ParaOrdnance, or S&W 1911s.

Please Read and Print Out Installation Instructions and Zeroing / Locking Down Instructions, located in the Instructions Section
